পণ্যের বিবরণ:
|
|
উৎপত্তি স্থল: | চীন |
---|---|
পরিচিতিমুলক নাম: | Glawall |
সাক্ষ্যদান: | SGS, ISO 9001,UL, CE |
মডেল নম্বার: | সম্পূর্ণ মডুলার ডাবল কাচের প্রাচীর |
নথি: | 25mm.pdf |
প্রদান:
|
|
ন্যূনতম চাহিদার পরিমাণ: | 10 বর্গক্ষেত্র |
মূল্য: | US$80.00 10 - 99 square meters |
প্যাকেজিং বিবরণ: | পাতলা পাতলা কাঠ |
ডেলিভারি সময়: | 20-25 দিন |
পরিশোধের শর্ত: | এল/সি, ডি/এ, ডি/পি, টি/টি, ওয়েস্টার্ন ইউনিয়ন |
যোগানের ক্ষমতা: | প্রতি মাসে 3000 বর্গমিটার |
বিস্তারিত তথ্য |
|||
সুবিধা: | প্রতিযোগিতামূলক মূল্য, ভাল পরিষেবা, উচ্চ পেশাদার, মানের গ্যারান্টি | অরিজির জায়গা: | গুয়াংডং, চীন |
---|---|---|---|
কারখানার শংসাপত্র: | হ্যাঁ | কারখানা এলাকা: | 20000 বর্গ মিটার |
উপাদান: | অ্যালুমিনিয়াম ফ্রেম, শাব্দ প্যানেল | সাউন্ডপ্রুফিং: | 38-45 ডিবি |
প্যানেল বেধ: | 60, 90.108 মিমি | কাচের ধরণ: | শক্তিশালী টেম্পারড গ্লাস |
বায়ুচলাচল: | বায়ুপ্রবাহ সিস্টেম | ওয়ারেন্টি: | 2 বছর |
বিশেষভাবে তুলে ধরা: | 90mm aluminum partition wall,double glass modular partition,aluminum frame partition system |
পণ্যের বর্ণনা
Advantage | Competitive price, good service, high professional, quality guarantee |
Place of Origin | Guangdong, China |
Factory Certification | Yes |
Factory Area | 20000 square meter |
Material | Aluminum Frame, Acoustic Panels |
Soundproofing | 38-45dB |
Panel Thickness | 60, 90, 108mm |
Glass Type | Strong tempered glass |
Ventilation | Airflow System |
Warranty | 2 Years |
Feature | Benefit |
---|---|
Pre-Assembled Double Glass Panels | Complete 5+5mm glass panels with integrated frame - no on-site assembly |
Plug-and-Play Channels | Simple installation with top/side/bottom aluminum tracks |
Tool-Free Connection | Patented click-lock system secures panels without tools |
Fast Installation | 2-person team can install 20m² in under 3 hours |
42dB Soundproof Rating | 10mm air gap effectively blocks office noise |
Thermal Insulation | Reduces HVAC costs by maintaining stable temperatures |
Step | Action |
---|---|
Step 1 | Install aluminum tracks (ceiling/floor/sides) using laser level |
Step 2 | Slide pre-assembled glass units into steel keel - no heavy lifting required |
Step 3 | Snap decorative covers over joints for perfect alignment |
Feature | Specification |
---|---|
Frame | 90mm powder-coated aluminum (20+ RAL colors) |
Glass | 5+5mm tempered (clear/frosted/tinted options) |
Acoustics | 42dB Rw (upgradable to 48dB with laminate) |
Fire Rating | EI30-EI60 available |
Max Height | 4m without additional support |
For Contractors | For Clients |
---|---|
70% faster installs = more projects per year | Immediate usability - No waiting for paint/drywall to cure |
50% less labor cost vs traditional systems | Adaptable layouts - Reconfigure teams without construction |
No construction waste - LEED points achievable | Premium aesthetics - Sleek, modern appearance |
